6 L i g h t i n g a n d T e s t i n g a n d F i t t i n g I n t e r n a l P a r t s
Diagram 6.13
Diagram 6.14
Ensure Coal
projections sit
on the chrome rail
Diagram 6.15
Note: There should be no
gap between the front of
'Coal 2' and the back of the
'L.H Front Coal'
Diagram 6.16
Diagram 6.17
Note: There should be no gap between the front
of 'Coal No 3' and the back of 'L.H Front Coal'
2482 h
2482 h 2482 f2482 g
2482 f2482 g
Diagram 6.18
L.H. FRONT COAL
R.H. FRONT COAL
COAL 1. (L.H.)
COAL 2. (L.H.)
COAL 3. (L.H.)
COAL 4. (R.H.)
COAL
SITS
ON PIN
PIN FITS
INTO
HOLE
