14
221100C
6 L i g h t i n g a n d T e s t i n g a n d F i t t i n g I n t e r n a l P a r t s
Diagram 6.19
Diagram 6.20
Diagram 6.22
2482 b2482 b
2482 a
COAL 5. (R.H.) COAL 6. (R.H.)
COMPLETE COALS
ARRANGEMENT
Note: 'Coal 5' sits
on top of 'Coal 4'
at R.H.S
Minimise gap
at front
Note: Ensure there are gaps
behind 'Coals 3, 5 and 6'.
6800
PIN
PIN FITS IN
GROOVE
ON REAR
COAL
COAL 7. (CENTRE) Diagram 26
PIN
To ensure that
the pin of N
O
7
sits in the base of
the groove, it may
be necessary
to adjust the
"rear coal".
To Next Page
