Glow-worm swift flow 80 - Page 54

54
221469B
4 Replacement of Parts
Diagram 4.23
Diagram 4.24
2270 S
FLUE ELBOW
SECURING
SCREW (4)
BOILER/MOUNTING
FRAME SCREW (2)
AIR DUCT
SECURING
SCREW (2)
CLAMPING SCREWS
UNION CONNECTION
AND SEALING WASHER
2316 S
Diagram 4.22
2268 S
SIDE INSULATION PIECES
LOWER REAR INSULATION
COMBUSTION
CHAMBER
FRONT PANEL
FRONT
INSULATION
CLIP
UPPER
REAR
INSULATION
