24
TELESCOPIC
TERMINAL ASSEMBLY
SEALING
COLLAR
TRIM RING
SECURING
COLLAR
FLUE
ELBOW
GASKET
(fitted)
SEALING
TA
PE (telescopic only)
Top Outlet Horizontal Concentric Flue Packs:
A2043600 Horizontal telescopic flue pack.
SCREW x 1
SCREW x 2
SCREW x 2
SCREW x 4
12841
Diagram 10.3
12842
10 Telescopic Flue - Length, Preparation and Installation
45
o
Bend
2000460485
(2off)
90
o
Bend
2000460484
0.5m
EXTENSION
2000460481
1m
EXTENSION
2000460482
2m
EXTENSION
2000460483
VERTICAL
FLUE
ADAPTOR
A2024600
Diagram 10.2
