Channel Function Time and Value DMX HEX %
macros
PAN 1 0° 01..01 01..01 0.5
1 90° 02..03 02..03 1.0
1 180° 04..05 04..05 1.7
1 270° 06..07 06..07 2.5
PAN 2 0° 08..09 08..09 3.3
2 90° 10..11 0A..0B 4.1
2 180° 12..13 0C..0D
4.9
2 270° 14..15 0E..0F 5.7
PAN 3 0° 16..17 11..11 6.5
3 90° 18..19 12..13 7.3
3 180° 20..21 14..15 8.0
3 270° 22..23 16..17 8.8
PAN 4 0° 24..25 18..19 9.6
4 90° 26..27 1A..1B 10.4
4 180° 28..29 1C..1D
11.2
4 270° 30..31 1E..1F 12
TILT size / phase see PAN 32..63 20..3F 13..25
PAN / TILT size / phase see PAN 64..95 40..5F 26..37
PAN / TILT (inverse) size / phase see PAN 96..127 60..7F 38..50
Circle size / phase see PAN 128..159
80..9F 51..62
Circle (inverse) size / phase see PAN 160..191
A0..BF 63..75
Lying eight size / phase see PAN 192..223
C0..DF
76..87
Random movement size / phase see PAN 224..255
E0..FF 88..100
15) Speed
Pan/Tilt movement speed from
controller
0..1 00..01 0..0..5
Pan/Tilt
Pan/Tilt, slow – fast
Use this channel also for the speed of
the movements (channel 14).
02..255 02..FF 1..100
16) Zoom
Wide - narrow (spot) 0…255 00…FF
0…100
17) Pattern
No pattern 0..2 00..02 0..1
250 pre-defined patterns
(see appendix A)
03..253 03..FD 2..99
Activates direct access to LED Pattern See channels 18-20 254..255
FE..FF 100
18) Pattern
Byte 1
Direct access to Pattern of LED 1..8
0…255 00…FF
0…100
19) Pattern
Byte 2
Direct access to Pattern of LED 9..16
0…255 00…FF
0…100
20) Pattern
Byte 3
Direct access to Pattern of LED 17..19
0..07 00…07
0..2.5
Compress-Mode 14 DMX channels
Channel Function Time and Value DMX HEX %
1) PAN-
coarse
0 .. 660° 0..255 00..FF 0..100
2) PAN-fine
High- Pos ... High- Pos + 2.6° (16 Bit) 0..255 00..FF 0..100
3) Tilt-
coarse
0 .. 300° 0..255 00..FF 0..100
4) Tilt-fine
High- Pos … High- Pos + 1.2° (16 Bit) 0..255 00..FF 0..100
5) Color
Colors adjustable via RGB 0..7 00..07 0..2.5
