GLP impression X4 - Page 15

GLP  German Light Products GmbH (Instruction version: 1.0) / from software version: 1.18/18/12/10/n 15
Channel Function Time and Value DMX HEX %
(fixed)
Color 01 - Red
1)
8..15 08..0F 3..5.5
Color 02 - Amber
1)
16..23 10..17 6..8.5
Color 03 - Warm Yellow
1)
24..31 18..1F 9..12.5
Color 04 - Yellow
1)
32..39 20..27 13..15.5
Color 05 - Green
1)
40..47 28..2F 16..18.5
Color 06 - Turquoise
1)
48..55 30..37 19..21.5
Color 07 - Cyan
1)
56..63 38..3F 22..24.5
Color 08 - Blue
1)
64..71 40..47 25..27.5
Color 09 - Lavender
1)
72..79 48..4F 28..30.5
Color 10 - Mauve
1)
80..87 50..57 31..34.5
Color 11 - Magenta
1)
88..95 58..5F 35..37.5
Color 12 - Pink
1)
96..103 60..67 38..40.5
White - CTO Color temperature
3200K
104..111
68..6F 41..43.5
White Color temperature
5600K
112..119
70..77 44..46.5
White - CTB Color temperature
7200K
120..127
78..7F 47..49.5
Rainbow Effect Stop
2)
128 80 50
Rainbow Effect
3)
slow - fast 129..223
81..DF 51..88
Rainbow Effect, random colors slow - fast 224.255 E0..FF 89..100
6) Red
Color mixing system - Red 0 - 100% 0..255 00..FF 0..100
7) Green
Color mixing system - Green 0 - 100% 0..255 00..FF 0..100
8) Blue
Color mixing system - Blue 0 - 100% 0..255 00..FF 0..100
9) White
Color mixing system - White 0 - 100% 0..255 00..FF 0..100
10) Shutter
Shutter closed 0..15 00..0F 0..5.5
Random Pulse effect slow - fast 16..47 10..2F 6..18.5
Up-dimming then Shutter closing
(random patterns)
slow - fast 48..79 30..4F 19..31.5
Shutter open then down-dimming
(random patterns)
slow - fast 80..111 50..6F 32..43
Up-dimming then down-dimming
(random patterns)
slow - fast 112..143
70..8F 44..56
Strobe effect pause 5s .. 1s 144..199
A0..C7 57..77
Strobe effect, slow - fast 1 Hz .. 10 Hz 200..239
C8..EF
78..94
Shutter open 240...249
F0..F9 95..97.5
Shutter open 251..255
FB..FF 99..100
11) Dimmer
Dimmer 0 - 100% 0..255 0..FF 0..100
12) Zoom
Wide - narrow (spot) 0…255 00…FF
0…100
13) Special
Pattern Block 1
 channel 14 0..3 00..03 0..1
Pattern Block 2
 channel 14 4..7 04..07 1.5..2.5
Change PWM frequency 100..200
64..C8 40..78
RESET
250..255
FA..FF 98..100
14) Pattern
No pattern 0..2 00..02 0..1
250 pre-defined patterns
(see appendix A)
03..253 03..FD 2..99
