GLP impression X4 - High Resolution Mode DMX Channels

GLP  German Light Products GmbH (Instruction version: 1.0) / from software version: 1.18/18/12/10/n 16
High Resolution (Extended) -Mode 21 DMX Channels
Channel Function Time and Value DMX HEX %
1) PAN-
coarse
0 .. 660° 0..255 00..FF 0..100
2) PAN-fine
High- Pos ... High- Pos + 2.6° (16 Bit) 0..255 00..FF 0..100
3) Tilt-
coarse
0 .. 300° 0..255 00..FF 0..100
4) Tilt-fine
High- Pos … High- Pos + 1.2° (16 Bit) 0..255 00..FF 0..100
5) Red-
coarse
Color mixing system – Red 0 - 100% 0..255 00..FF 0..100
6) Red-
fine
Color mixing system – Red-Low 0..255 00..FF 0..100
7) Green-
coarse
Color mixing system – Green 0 - 100% 0..255 00..FF 0..100
8) Green-
fine
Color mixing system – Green-Low 0..255 00..FF 0..100
9) Blue-
coarse
Color mixing system – Blue 0 - 100% 0..255 00..FF 0..100
10) Blue-
fine
Color mixing system – Blue-Low 0..255 00..FF 0..100
11) White-
coarse
Color mixing system – White 0 - 100% 0..255 00..FF 0..100
12) White-
fine
Color mixing system – White-Low 0..255 00..FF 0..100
13) Shutter
Shutter closed 0..15 00..0F 0..5.5
Random Pulse effect slow - fast 16..47 10..2F 6..18.5
Up-dimming then Shutter closing
(random patterns)
slow - fast 48..79 30..4F 19..31.5
Shutter open then down-dimming
(random patterns)
slow - fast 80..111 50..6F 32..43
Up-dimming then down-dimming
(random patterns)
slow - fast 112..143
70..8F 44..56
Strobe effect pause 5s - 1s 144..199
A0..C7 57..77
Strobe effect, slow - fast 1 Hz - 10 Hz 200..239
C8..EF
78..94
Shutter open 240...249
F0..F9 95..97.5
Shutter open 251..255
FB..FF 99..100
14) Dimmer-
coarse
Dimmer 0 - 100% 0..255 0..FF 0..100
15) Dimmer-
fine
Dimmer - Low 0..255 0..FF 0..100
16) Zoom
Spot - Flood 0…255 00…FF
0…100
17) Special
Pattern Block 1
 channel 18 0..3 00..03 0..1
Pattern Block 2
 channel 18 4..7 04..07 1.5..2.5
Change PWM frequency 100..200
64..C8 40..78
RESET
250..255
FA..FF 98..100
18) Pattern
No pattern 0..2 00..02 0..1
250 pre-defined patterns
(see appendix A)
03..253 03..FD 2..99
Activates direct access to LED Pattern
See channels 18-20 254..255
FE..FF 100
19) Pattern
Byte 1
Direct access to Pattern of LED 1..8
0…255 00…FF
0…100
20) Pattern
Byte 2
Direct access to Pattern of LED 9..16
0…255 00…FF
0…100
