Black plate (32,1)
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-6081485) - 2014 - CRC - 12/6/13
10-32 Vehicle Care
6. Push the bulb socket in and turn
it clockwise.
7. Reinstall the interior trim access
panel.
License Plate Lamp
Lamp Assembly
Bulb Assembly
1. Bulb Socket
2. Bulb
3. Lamp Assembly
To replace one of these bulbs:
1. Open the liftgate partway. See
Liftgate on page 2-9.
2. Push the left end of the lamp
assembly toward the right.
3. Pull the lamp assembly down to
remove it from the liftgate.
4. Turn the bulb socket (1)
counterclockwise to remove it
from the lamp assembly (3).
5. Pull the bulb (2) straight out of
the bulb socket (1).
6. Push the replacement bulb
straight into the bulb socket and
turn the bulb socket clockwise to
install it into the lamp assembly.
7. Push the lamp assembly into the
liftgate engaging the clip side
first.
8. Push on the lamp side opposite
the clip until the lamp assembly
snaps into place.
Replacement Bulbs
Exterior Lamp
Bulb
Number
Auxiliary Taillamp 161
Back-Up Lamp 921
Fog Lamp H11 LL
Headlamp
High Beam
9005LL
