Black plate (4,1)

GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/

Mexico-6081485) - 2014 - CRC - 12/6/13

12-4 Technical Data

Engine Drive Belt Routing

2.4L L4 Engine

3.6L V6 Engine
