312 Vehicle Care
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.
Fuses Usage
F1 Body control
module 6
F2 Diagnostic link
F3 Electric steering
column lock
F4 –
F5 Logistics
F6 HVAC
F7 Body control
module 3
F8 Head-up display (if
equipped)
F9 Right front
heated seat
F10 Airbag
F11 Electronic precision
shift
F12 Amplifier
F13 Body control
module 7
Fuses Usage
F14 Left front
heated seat
F15 Instrument panel
switch bank
F16 Sunroof
F17 Body control
module 1
F18 Instrument panel
cluster
F19 –
F20 Rear seat
entertainment
F21 Body control
module 4
F22 Infotainment
F23 Body control
module 2
F24 USB charger/
Wireless charging
module
F25 Ultrasonic
parking aid
F26 CIM
Fuses Usage
F27 –
F28 HVAC display
F29 Radio
F30 Steering wheel
controls
F31 Front blower
F32 AC DC inverter
F33 Driver power seat
F34 Passenger
power seat
F35 Battery IEC 1 feed
F36 Electric power
steering
F37 Rear seat
entertainment/USB
charge/Wireless
charging module
F38 Body control
module 8
F39 –
F40 –
F41 –
