Vehicle Care 10-7
A. Engine Air Cleaner/Filter
on
page 10‑16
.
B. Coolant Surge Tank and
Pressure Cap. See Cooling
System on page 10‑17.
C. Positive (+) Terminal. See Jump
Starting on page 10‑92.
D. Battery on page 10‑30.
E. Remote Negative (−) Terminal
(Out of View). See Jump
Starting on page 10‑92.
F. Automatic Transmission
Dipstick (Out of View). See
“Checking the Fluid Level”
under Automatic Transmission
Fluid (4-Speed Transmission)
on page 10‑11
or Automatic
Transmission Fluid (6-Speed
Transmission) on page 10‑13.
G. Engine Oil Fill Cap. See “When
to Add Engine Oil” under
Scheduled Maintenance
on
page 11‑2
.
H. Engine Oil Dipstick (Out of
View). See “Checking Engine
Oil” under Scheduled
Maintenance on page 11‑2.
I. Engine Cooling Fan. See
Cooling System on page 10‑17.
J. Power Steering Fluid Reservoir.
See Power Steering Fluid
on
page 10‑25
.
K. Brake Master Cylinder
Reservoir. See Brake Fluid
on
page 10‑28
.
L. Engine Compartment Fuse
Block on page 10‑46.
M. Windshield Washer Fluid
Reservoir. See “Adding Washer
Fluid” under Washer Fluid
on
page 10‑26
.
If the vehicle has a diesel engine
and/or an Allison Transmission, see
the Duramax
®
Diesel Supplement.
Engine Oil
Checking Engine Oil
For diesel engine vehicles, see
“Engine Oil” in the Duramax Diesel
Supplement.
It is a good idea to check the engine
oil level at each fuel fill. In order to
get an accurate reading, the oil
must be warm and the vehicle must
be on level ground.
The engine oil dipstick handle is a
yellow loop. See Engine
Compartment Overview
on
page 10‑6
for the location of the
engine oil dipstick.
1. Turn off the engine and give the
oil several minutes to drain back
into the oil pan. If this is not
done, the oil dipstick might not
show the actual level.
2. Pull out the dipstick and clean it
with a paper towel or cloth, then
push it back in all the way.
Remove it again, keeping the tip
down, and check the level.
