MENU
The Menu provides a convenient way to customise your
radios settings. The following Menu options are available
.
MENU
ITEM
FUNCTION AVAILABLE
SETTINGS
SQL Adjust Squelch Level SQL--1 TO SQL--9
CTCSS Set CTCSS or DCS Code CTCOF
CTC01 -> CTC50
DC001 -> DC104
LIGHT Adjust Display Brightness See Display
COLOR Adjust Display Colour See Display
WHITE Adjust Colour Saturation See Display
S-METER/
BATT
Display S-Meter or Battery
Voltage on the LCD
S-MET / BATT
BEEP Adjust Key Beep-Tone
Volume
VOL--0 ->
VOL--9
DVC Activate/ Deactivate the
Dynamic Volume Control
DVCOF / DVCON
SPK Disable the Speaker in
the Radio
SPKON / SPKOF
MIC Adjust the Microphone
Sensitivity
MIC+0 > MIC+9
To use the Menu
Press and hold the key until the radio beeps. ‘SQL’ will
be displayed indicating the first Menu item (Squelch setting
mode) is selected.
Briefly press the
key to cycle through the Menu items.
Press the
or keys to adjust the selected
Menu item.
When finished, press and hold the
key to exit the
Menu or wait until the Menu times out.
To adjust the Squelch sensitivity from the Menu
1. Press and hold the
key for several seconds. The
radio will enter Menu mode and ‘SQL’ will be displayed.
2. Press the
or keys to adjust the Squelch value.
3. To exit, press and hold the
key or wait for the
Menu to time out.
BACKLIGHTING
The Liquid Crystal Display and keys are backlit for easy
viewing at night. The backlight remains on while the radio
is switched on. The backlighting brightness, colour and
saturation are all fully adjustable for personal preference.
To adjust the Backlighting
1. Press and hold the
key for several seconds. The
radio will enter Menu mode and ‘SQL’ will be displayed.
2. Press the
key repeatedly until ‘LIGHT’ is displayed.
3. Press the
or keys to adjust the backlight
brightness.
4. Press the
key briefly. ‘COLOR’ is displayed.
5. Press the
or keys to adjust the backlight
colour. The full spectrum of colours is available.
6. Press the
key briefly. ‘WHITE’ is displayed.
7. Press the
or keys to adjust the whiteness or
colour saturation of the selected backlight colour from
full colour to white (no colour).
8. To exit, press and hold the
key or wait for the
Menu to time out.
TIP:
For the deepest colour range, reduce the WHITE setting.
SIGNAL METER/BATTERY METER
The TX3350 includes a digital signal strength meter that
shows the relative strength of incoming signals on the
display. The meter displays signal strengths in values from 0
(very weak) to 9 (very strong). Signals that exceed strength 9
are shown as 9+
PAGE 8 INSTRUCTION MANUAL TX3350
