T X 3 5 1 0 / T X 3 5 2 0 / T X 3 5 4 0 I N S T R U C T I O N M A N UA L PA G E 5
•
High Contrast Liquid Crystal Display: Fully detailed LCD
provides a visual indication of the selected channel and all
selected functions at a glance.
•
User Programmable Receive-Only Channels: Use the
radio’s front panel controls to program up to 95 of your own
receive-only channels (in 5 banks of 19 channels) within the
403-520 MHz frequency range.
•
In-Built CTCSS & DCS:
User selectable Continuous Tone
Coded Squelch and Digital Coded Squelch System option
provides silent channel operation on individual channels.
•
In-Built Selcall with QUIET Mode:
Provides selective
calling of individuals or groups with fully user-adjustable
5 tone transmitted Selcall Ident. Also allows alphanumeric
naming of up to 10 Idents for easier caller identification.
•
User selectable Wide/Narrow Receive Filter
•
Dual Microphone Input Sockets:
Front and Rear
Microphone sockets to match most installation needs. Both
sockets can be used independently or simultaneously.
•
Over Voltage Protection:
Special overvoltage detection
circuitry protects the radio and warns of excessive voltage
conditions by flashing the display.
•
Surface Mount Technology:
The very latest surface
mount component types, design and assembly techniques
and quality control procedures are used to ensure the
highest performance and reliability.
•
Designed and Manufactured in Australia: Totally
designed and manufactured in Gladesville to meet the
demanding needs of the Australian community.
TX3510/TX3520 FRONT PANEL CONTROLS
GENERAL OPERATIONS
Volume Control
Liquid Crystal Display
Channel Switch
Push for Squelch level/
Priorty channel
Menu/
Function
Scan/
OS-GS
Quiet/
Duplex
Squelch/
Alpha
Front Mic Input
PUSH
PRIORITY
MENU
F
PUSH
SQL LVL
SCAN
OS/GS
QUIET
DUP
SQL
ALPHA
