GMI D1030S User Manual

6
D1030 - SIL 2 Switch / Proximity Detector Repeater Relay Output G.M. International ISM0008-17
MODEL D1030D
=
=
13
14
3 +
4 -
8 NC
2 NO
1 COM
Supply 24 Vdc
Out 1
+
-
In 1
15
16
7 NC
6 NO
5 COM
+
-
In 2 Out 2
=
=
voltage free
Contact
Proximity
Proximity
Common
positive
connection
voltage free
Contact
MODEL D1030S
=
=
13
14
3 +
4 -
8 NC
2 NO
1 COM
Supply 24 Vdc
Out 1-A
+
-
In 1
7 NC
6 NO
5 COM
Out 1-B
=
=
voltage free
Contact
Proximity
Function Diagram
HAZARDOUS AREA ZONE 0 (ZONE 20) GROUP IIC,
HAZARDOUS LOCATIONS CLASS I, DIVISION 1, GROUPS A, B, C, D,
CLASS II, DIVISION 1, GROUPS E, F, G, CLASS III, DIVISION 1,
CLASS I, ZONE 0, GROUP IIC
SAFE AREA, ZONE 2 GROUP IIC T4,
NON HAZARDOUS LOCATIONS, CLASS I, DIVISION 2,
GROUPS A, B, C, D T-Code T4, CLASS I, ZONE 2, GROUP IIC T4
Relay contact shown in de-energized position
