GO-DEVIL SURFACE DRIVE FNR User Manual

16
SPECIAL TOOLS TO SERVICE SURFACE DRIVES
TOTAL $325.00
These tools can be rented for $20.00 plus shipping with a $325.00 deposit.
OTHER TOOLS NEEDED TO SERVICE FNR
SURFACE DRIVES
18” PIPE WRENCH
1/2” DRILL
8” OR 10” CRESCENT WRENCH
1-1/16” SOCKET OR COMBINATION WRENCH
1-1/8” DEEP SOCKET OR COMBINATION WRENCH
PAIR OF CHANNEL LOCK PLIERS
4 TO 5 LB HAMMER
5/16” DRILL BIT
1-1/4” X 6-1/2” LONG PVC PIPE (to install lower seals)
11/16” CROWFOOT (to loosen and tighten engine housing to frame)
½” x ¾” ADAPTER FOR SLIDE HAMMER (to remove transmission)
¾” SHAFT SLIDE HAMMER
2- ½” BOLTS 2 -1/2” long (to lock transmission when torqueing bolts)
3/16” HEX SOCKET DRIVER (to tighten brake disc bolts)
1/8” HEX SOCKET DRIVER (for transmission drain plug)
5/32” HEX SOCKET DRIVER (for installing transmission housing to sprocket)
TWO STRIPS OF .063” MATERIAL (for setting brake shoes)
NEVER SIEZE
BLUE LOCTITE
SYRINGE TO FILL GEARBOX
PART #
DESCRIPTION
USED FOR
PRICE
DIE114X1
1-1/4” HEX DIE
HEX DIE (TO REPAIR SHAFT TUBE THREADS)
$100
SHBUPU
PULLER FOR
SHAFT & BUSHINGS
(SLIDE HAMMER)
USED WITH:
SHAFT ADAPTER TO REMOVE SHAFT
BUSHING PULLER- TO REMOVE BUSHING-
(MUST USE 1-1/8” TAP TO THREAD INNER
BUSHING FOR BUSHING PULLER INSERTION.)
$50
SHAD
SHAFT ADAPTER
USED WITH PULLER TO REMOVE SHAFT
$15
BUPU1
BUSHING PULLER
USED WITH PULLER TO REMOVE BUSHING
$20
BUIN1
BUSHING INSTALLER
TO INSTALL BUSHINGS
$10
T118
1-1/8” TAP
USED TO THREAD INNER BUSHING FOR
INSERTION OF BUSHING PULLER FOR
REMOVAL OF BUSHING.
$60
R1
1” REAMER
AFTER BUSHING INSTALLATION, USED TO
REAM THE BUSHING FOR PROPER SHAFT
PLACEMENT/FIT.
$70
