Go Power 10 AMP RVC-MPPT User Manual

[page 6] | gpelectric.com
3. APPEARANCE
NO. NAME NO. NAME
1 Instance Indicators 7 Battery Negative
2 PV Indicator 8 Extreme Temp Sensor
3 Battery Indicator 9 RV-C Connector
4 Solar Positive 10 Remote Port
5 Solar Negative 11 Instance Cong Button
6 Battery Positive 12 Installation Holes

Go Power 10 AMP RVC-MPPT Specifications

General

Battery Voltage Range	8V – 16V
Battery Type	Lead Acid (AGM, GEL, Flooded), LiFePO4
Max Charge Current	10A
Max Panel Input Voltage	100Voc
Max PV Power Input	200W
Conversion Efficiency	≤98%
MPPT Tracking Efficiency	>99%
No-Load Loss	<10mA
Grounding	Negative
Max Wire Gauge	8 AWG
Operating Temperature	-35 to 45°C
Storage Temperature	-35 to 75°C
Humidity	95% N.C.
Water Ingress Protection	IP32
Altitude	< 3000m
Protection	Solar/battery reverse polarity Solar/battery over voltage Solar/battery short circuit Over temperature

Weight and Dimensions

Dimensions (H x W x D)	3.35” x 6.1” x 1.57”
Weight	0.67lbs (300g)
