Go Power GP-ISW-R-12 User Manual

page 6 | gpelectric.com
4. INTRODUCTION
6 PHONE JACK CONNECTOR
1. Before connecting, make sure to switch the inverter to REMOTE mode.
2. Connect the RJ-11 cable between the ISW-R remote and the inverter.
WARNING!
DO NOT use a standard telephone cable.
A
6
1
B
6
1
9.6±0.2
9.6±0.2
12.4±0.3
6.5±0.2
14.6±0.3
3.1±0.2
12.4±0.3
6.5±0.2
14.6±0.3
3.1±0.2
A
6
5
4
3
2
1
WIRE COLOR
YELLOW
BLUE
GREEN
WHITE
BLACK
RED
B
6
5
4
3
2
1
