7 JP1
The JP1 is to set either the Return Override function or the Ignition Lockout
function.
• JP1 jumper “Short” - Return Override function:
Turns ON the inverter when the auxiliary input wiring is connected to the
reversed gear shift with 12 volts.
• JP1 jumper “Open” - Ignition Lockout function:
Turns OFF the inverter when the auxiliary input wiring is connected to the ACC
with 12 volts.
• The connector which is connected to AUX power must be used with a 12V /
0.5A fuse.
Triggered signal
JP1 Inverter Status
AUX
1 Open OFF
0 Open ON
1 Short ON
0 Short OFF
Note: default mode is Open.
