[page 10] | gpelectric.com
STATUS, SETTINGS AND COMMANDS
Type Battery Type GEL
Flooded, GEL,
AGM, Li, USER
(Custom)
Since each type of battery is charged and
maintained di󰀨erently, the battery type
must be set to match the battery connect-
ed to the controller.
When the battery type is changed the fol-
lowing characteristics will change accord-
ing to the battery type.
Nom V System Voltage AUTO AUTO, 12V, 24V
The nominal voltage of the battery bank.
This is only congurable for lithium bat-
teries. For all other battery types it is auto
deteced.
AH Capacity 200Ah 1 - 9999Ah
The nominal battery capacity is used to
adjust the capacity to match the batteries
being used in the application
Advanced Settings
OVP
High Voltage
Disconnect
16V 0 - 17V
The voltage when the solar controller will
disconnect the charger from the battery
and indicate a high voltage fault
Eq V
Equalization
Voltage
14.1V 0 - 17V
The equalize voltage is the voltage setpoint
used during an equalize maintenance
cycle.
Bulk V
Bulk-Absorption
Voltage
14.1V 0 - 17V
When the battery reaches the bulk-
absorption set point, the controller will start
to operate in the absorption stage.
Float V Float Voltage 13.7V 0 - 17V
After the absorption stage, the controller
will reduce the battery voltage to the oat
voltage set point.
Chg Rtn Recharge Voltage 13.2V 0 - 17V
This is the voltage setpoint that triggers a
new charge cycle.
LRV
Over-discharge
return
12.8V 0 - 17V
The over-discharge return voltage is
the voltage at which the battery over
discharge fault is cleared when the battery
is charging back up again from and over-
discharged state.
Warn V
Under Voltage
Warning
12.0V 0 - 17V
The under-voltage warning level is the
voltage at which the under-voltage warning
fault state is entered to indicate that an
under-voltage condition has be reached.
ODV
Discharge Limit
Voltage
11.0V 0 - 17V
The discharge limit voltage is the voltage
at which the battery will be disconnected
from the solar controller so there is no
current draw from the battery. When solar
power su󰀩cient to charge the battery
becomes available the battery will be
connected again.
Batt1 ODVD
Bank 1 Over-
discharge Delay
Time
5.0S 0 - 300s
The over-discharge time delay is the
time that the controller will wait when
it sees the voltage fall below the over-
discharge voltage and the discharge limit
voltage before entering a fault condition.
The purpose of this setting is to prevent
the controller from alerting the user
or disconnecting the battery when a
temporary surge is drawn from the battery
such as a starter motor or AC unit that
drops the voltage of the battery.
