Godex BP300 - Page 6

3
1 Barcode Printer
Open The Printer Cover
RELEASE CATCH(Left)
SCREW(Left)
Screw for adjusting the print head pressure
LABEL SUPPLY MODULE
- LABEL SUPPLY HUB
- LABEL GUIDE PLATES(Set of 2)
RELEASE CATCH(Right)
SCREW(Right)
Screw for adjusting the print head pressure
RIBBON REWIND WHEEL
HOLDER OF RIBBON REWIND CORE
003
Open The Printing Mechanism
PLATEN
LABEL GUIDE(Right)
LABEL SENSOR
LABEL GUIDE(Left)
ADJUSTMENT SCREW
Screw for adjusting
the printer line
PRINTING MECHANISM
RIBBON SUPPLY
WHEEL
HOLDER OF
RIBBON SUPPLY CORE
PRINT HEAD
