Godiva WTB4010 - Special Tools

MAINTENANCE MANUAL
GP/146/99. Issue 9. Octobe
r
2005
Section 16
Special Tools available for servicing
World Series Pumps
DESCRIPTION Part Numbers
WTA2010 WTB2010 WTA4010 WTB4010
WTA3010 WTB3010 WTA6010 WTB6010
ASSY TOOL - BRG TO SHAFT 60275 60275 60275 60275
ASSY TOOL - BRG TO SHAFT 60275/01 60275/01 60275/01 60275/01
ASSY TOOL - SEAL TO HOUSING 60275/02 60275/02 60275/02 60275/02
ASSY TOOL - HP IMPELLER CHECK 60275/03 60275/03 60275/03 60275/03
EXTRACTION TOOL - LP IMPELLER 60275/04 60275/04 60275/04 60275/04
EXTRACTION TOOL - HP IMPELLER 60275/05 60275/05 60275/05 60275/05
ASST TOOL - RELIEF VALVE 60275/06 60275/06 60275/06 60275/06
ASSY TOOL - SEAL TO HOUSING 60275/07 60275/07 60275/07 60275/07
ASSY TOOL - CARBIDE SEAL TO HP IMP. 60275/08 60275/08 60275/08 60275/08
ASSY TOOL - GASKET TO FILTER BODY 60275/09 60275/09 60275/09 60275/09
ASSY TOOL - 'O' RING TO PUMP BODY 60275/10 60275/10 60275/10 60275/10
ANTI - TURN TOOL 60275/11 60275/11 60275/11 60275/11
ROTATING TOOL - SEAL WEAR RING 60275/12 60275/12 60275/12 60275/12
EXTRACTION TOOL (MECH SEAL ASSY) 60275/13 60275/13 60275/13 60275/13
BEARING NUT SPANNER (GEARBOX) 60275/14 60275/14 60275/14 60275/14
©Hale Products Europe LTD, Warwick
GP/146/99
WTmaint - Issue9. 10-2005October 2005
39
