2005
CONTENTS
SECTION PAGE
SAFETY 6
GENERAL DESCRIPTION 7-8
LUBRICATION 9
PROTECTION AGAINST FROST 10
SECTION: 1 SUCTION TUBE & FRONT WEARING RING 11
2 WEARING RING MAINTENANCE 11
3 LOW PRESSURE IMPELLER 12
REAR WEAR RING & COVER PLATE
4 HIGH PRESSURE IMPELLER 12
5 CARBON SEAL & SEATING ASSEMBLY 16
6 VOLUTE BODY 18
7 LOW PRESSURE MANIFOLD & 19-20
FILTER HOUSING
8 PRIMING SYSTEM 21-27
9 PUMP HEAD 28
10 FRONT END OIL SEAL & WEAR RING 28
11 REAR END OIL SEAL & WEAR RING 30
12 BEARING HOUSING 31
13 GEARBOX (Optional) 32
14 PUMP TESTS 34
15 DELIVERY VALVES 35-38
16 SPECIAL TOOLS 39
©Hale Products Europe LTD, Warwick
GP/146/99
WTmaint - Issue9. 10-2005October 2005
5
