OPERATION
The indicator must indicate the monitoring mode constantly via the green LED Betrieb
[Operation].
During a filling of the tank, an alarm is indicated via the red LED Alarm, the integrated buzzer,
and any connected external alarm units when the response level is reached (according to the
adjusting dimension X of the probe) so that the filling procedure can be ended on time.
An alarm is also indicated in case of a possible line disconnection or short circuit in the probe
circuit.
With the Alarmton Quittieren [Reset Alarm Sound] button, both the integrated acoustic
alarm and the Alarm 2 output can be reset (deactivated). The LED Alarm, however, remains
in operation. After the liquid level in the tank sinks (the probe is no longer submerged in liquid,
e.g. due to withdrawal), the indicator switches to monitoring mode again.
Operation includes MAINTENANCE.
FUNCTION CHECK
By pressing the Prüfen [Test] button, the alarm function in monitoring mode may be checked:
Display red LED Alarm and buzzer tone. After the button is released, the alarm indication
disappears.
ERROR MESSAGE/MEANING
Operation mode
Status of
Betrieb
[Operation]
LED + Output
Betrieb
[Operation] *1
Alarm
LED
Alarm
buzzer
Output
Alarm 1
Output
Alarm 2
Normal operation
(Filling level below the probe
response height)
ON
OFF
OFF
OFF
OFF
Alarm
Filling level reaches probe
response height when filling
ON
ON
ON
ON
ON
Alarm acknowledged
(with button)
ON
ON
OFF
ON
OFF
Failure of the auxiliary
energy
OFF
OFF
OFF
OFF
OFF
Disruption
of the line between the
measuring transducer and
the probe or of the PTC
thermistor
ON
ON
ON
ON
ON
Short circuit
of the line between the
measuring transducer and
the probe or of the PTC
thermistor
ON
ON
ON
ON
ON
The relay outputs Alarm 1 and Alarm 2 are not monitored, i.e. a line disconnection or a short
circuit to the connected signalling and control devices is not recognised and indicated by the
measuring transducer.
*1 Output Betrieb [Operation] only with type BC-1-1, BC-1-2 and BC-1-4
Overfill prevention divice type BC-1
part no. 308 393 _15 700 71 a
