ASSEMBLY
Before assembly, check that the product is complete and has not suffered any damage during
transport.
In Germany, the assembly of the BC-1 overfill prevention divice is to be carried out:
• for water-endangering substances by a company specialised in terms of water law
• for water-endangering substances by a specialised company if it is excluded from the
obligation to employ a company specialised in terms of water law according to national
regulations
Electric work is always to be carried out by a trained electrician. These requirements also
apply for the start-up, maintenance and repair work of the overfill prevention divice.
Switzerland: The installation may only be carried out by experts with knowledge in electrical
engineering as well as regarding explosion and fire protection.
The permits, approvals, and certificates legally required for the execution of building
projects are not replaced by the general building permit and this assembly and
The specialised company and the operator must observe, comply with and understand all of
the following instructions in this assembly and operating manual. For the system to function
as intended, it must be installed professionally in compliance with the technical rules
applicable to the planning, construction and operation of the entire system.
These regulations also include the accident prevention regulations of the employers’ liability
insurance associations, the VDE regulations, and the installation and operating instructions.
The specialist installer must enter and confirm that the safety device was installed in
accordance with the assembly and operating manual and the guidelines in the general
building-authority approval in the printed installation certificate.
The indicator (with IP 30 type of protection) should be installed on the wall of a
regularly used, dry room. The device is to be installed at a suitable place on the wall.
For assembly in the weatherproof outdoor area, the version with IP 65 type of
Installation of the display unit
1. Mount the display unit to the wall in a suitable position.
2. After loosening the four screws, open the display unit by removing the cover.
3. Mount the display unit to a smooth vertical wall by means of dowels. Mount the housing
of the display unit by the four fixing holes with the enclosed screws and anchors. Take
care not to damage the housing.
4. After connecting the terminals and setting the unit up, replace the cover.
If the indicator is installed in a closed housing (e.g. control cabinet), the connection of
external signal generators and operating elements is required at a suitable position
(alarm horn or lamp, operating light, acknowledgement button, test key).
Overfill prevention divice type BC-1
part no. 308 393 _15 700 71 a
