ÜBERSICHT RÜCKSEITE
| RÜCKSEITE
NETZVERSORGUNG
IEC NETZSTECKER
mit integrierter
Sicherungshalterung 6,3A T
5x20 mm an 100/240V
BTL Taste drücken
für Monobetrieb, die
korrespondierende LED wird
blau.
DF Taste drücken für
niedrigen Dämpfungsfaktor
(low), die korrespondierende
LED wird blau.
BAL Taste drücken, um die
XLR Eingänge zu aktivieren,
die korrespondierende LED
wird blau.
5
8
Hauptschalter EIN/AUS
9
3
GN LINK
12V IN/OUT (3.5mm) zur
Synchronisation mit anderen
Gold Note Geräten.
4
1
6 7
2 3
4
8
9
LAUTSPRECHER-
AUSGANG
6
Rechter Kanal
AUDIOEINGÄNGE
LINE EINGÄNGE
1
RCA unsymmetrisch
XLR symmetrisch
2
XLR symmetrisch
Linker Kanal
MONOBETRIEB (BTL)
Siehe Seite 22 für mehr
Informationen.
ACHTUNG
Die “links -“ und “rechts +”
Ausgänge sind elektronisch
zusammengeschaltet.
7
20
5
