Golden Technologies PR-756MC - Lm502

REVA_082012
39
LM502 LIFT FRAME PARTS LIST
Part Number Description
Qty. Per
Unit
BB5506 1/4" LOCK WASHER 17
BB5514 HAIR PIN 12
BB5530 5/16 X 1 LEG LEVELER 13
BB5535 1/8 NYLON PLASTIC WASHER 6
BB5548 5\16" X 3" TAP BOLT GRADE 5 ( to attach lift frame to chair ) 4
BB5549 3/8 NYLON PLASTIC WASHER 4
BB5554 5/16" NYLON LOCK NUT 6
BB5583 1 1/4" X 1 1/4" END CAP 12
BB5584 1/2" X 1/2" SHOULDER BOLT 2
BB5585 1/2" X 3 1/4" CLEVIS PIN 2
BB5586 1/2" X 2 1/2" SHOULDER BOLT 2
BB5587 3/8" X 1 1/4" SHOULDER BOLT 1
BB5588 3/8"-16 NYLON LOCK NUT 4
BB5589 3/8" X 1 3/4" SHOULDER BOLT 3
BB5590 3/8" X 2 1/2" SHOULDER BOLT 2
BB5591 5/16" X 1 1/2" HEX CAP SCREW ( to attach back to mechanism ) 2
BB5592 5/16" X 2" HEX CAP SCREW 9 to ( to attach back to mechanism ) 4
BB5593 NYLON WASHER .750 X .502 X .1875 8
BB5594 NYLON WASHER 1.25 X .502 X .0625 2
BB5596 1/2" X 4" CLEVIS PIN 4
BB5597 1/2" X 2 1/2" CLEVIS PIN 2
BB5598 1/2" X 2 1/4" CLEVIS PIN 4
BB5599 5/8" X 1/2" X 1/2" BUSHING 28
BB5599KIT BUSHING KIT FOR 502 1
GMOKI-28 26-28 WIDE MOTOR 2
GMOKICB 26-28 WIDE CONTROL BOX 1
GMOKI1502OM
SINGLE MOTOR 502 1
GM502Y Y CONNECTOR 1
LIF
T
-502 COMPLE
T
E 502LIFT FRAME
A
SSEMBLY
(
Recline bar not included
)
1
LM502 502 LIFT FRAME 1
LM5021
T
OP PIECE 502 LIFT FRAME 1
LM5022 STRAIGHT BAR 502 LIFT FRAME 1
LM5023 H-B
A
R 502 LIFT FRAME 1
LM5024 BASE PIECE 502 LIFT FRAME 1
RS502 RECLINE STRAP 502 LIFT FRAME 4
ZKAD-1 Hand Wand Auto Drive for Lift Chairs
1
RECLINE BAR FOR 502 LIFT FRAME
RB502 RECLINE BAR FOR 502 CHAIR 1
RECLINE MECHANISM FOR 502 LIFT FRAME
RM502BR BACK RECLINE MECHANISM 502 1
RM502LH RECLINE MECHANISM LEFT SIDE 502 1
RM502RH RECLINE MECHANISM RIGHT SIDE 502 1
LEFT AND RIGHT IS DETERMINED BY SITTING IN CHAIR
TRANSFORMER FOR 502 SERIES LIFT FRAME
GM1501-A Motor Chair Transformer
2
GM1501-APUS Transformer Cord 2
CALL TECHNICAL SERVICE FOR FABRIC, FOAM, SPRING AND WOOD PART NUMBERS AND PRICING
