37
Final drive lever
The lever can be moved in four positions (plus neutral):
Standard speeds (Man)
Low speeds (Tortoise)
High speeds (Hare)
Reverse speeds (REV)
Selection is not synchronized.
To select the required range:
• stop the machine
• disengage the main clutch
• select the required range
Reverse shuttle lever
The lever has two positions (plus neutral):
forward
reverse
Selection is synchronized.
Even though selection is synchronized,
proceed as described below to select the
forward or reverse speeds:
• stop the machine
• disengage the main clutch
• select the forward or reverse speed.
