golmar EL632 GB2A

DESCRIPTION OF THE EL632 GB2 SOUND MODULEA
4
Microphone.
Speaker.
Front.
Sound module push buttons (x2).
Connection block (GB2 bus).
Push button connector (in unused).villas
Back.
Positive, negative (12Vdc output for Golmar DC lock ).: release
: lock releaseContact “C” for (Relay 1).
: lock releaseContact “NO” for (Relay 1).
: Input for external door opening button (Relay 1).
: releaseContact “NO” for lock (Relay 2).
: releaseContact “C” for lock (Relay 2).
: Input for external door opening button (Relay 2).
: Input for external call button (push button 1).
: Input for external call button (push button 2).
: .Connection BUS (non-polarised)
: Connection BUS (non-polarised).
Push button number.
Color camera.
+,
C1
NA1
AP ,AP+
NA2
C2
AP+,AP
P1
P2
BUS
BUS
_
Connection terminals:
Note: See wiring diagrams for connections (pages 12-19).
Configuration dip switch.
Do not use (in unused)villas .
LEDs (visual indications for people with impaired hearing).
LEDs (activation in low light conditions).
Internal use.
_
_
Do not use (internal use).
Description of the EL632 GB2 sound module:A
NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS
Do not use (in unused)villas .
Do not use (in unused)villas .
