Important: Do not change the factory default position of the configuration jumper.
Description of the door panel LED lights (for low light conditions):
The door panel LED lights will turn on during a call if there is low light, allowing the
person who called to be seen on the apartment's monitor.
*
( )
*
( )
Factory default setting.
Description of the visual indications on the door panel:
Visual indications on the door panel for people with impaired hearing :
- :While calling LED will turn on during the call and while in communication.
- : .During communication LED will turn on during the communication process
- :During door release LED will turn on during door release.
- :End of communication LEDs and will turn off.
- :Calling at one door panel while another door panel is communicating LED will turn on for 3 seconds.
- :While calling and the monitor is in “Do not disturb” mode LED will turn on for 4 seconds.
- :While calling (apartment with no monitor or telephone) LED will turn on for 4 seconds.
Description of the vocal synthesis (audible indications on the door panel):
Audible indications from the door panel for people with impaired vision.
If the vocal synthesis in the sound module is activated (see pages 7 and 9 for setup), a voice with the following
messages can be heard from the door panel:
- While calling: “Call is in progress”.
- Start communication: “You can speak now”.
- During door release: “Door is open”.
- End of communication: “Communication is finished”.
- Calling at one door panel while another door panel is communicating:“ System is busy, try later”.
- While calling and the monitor is in "Do not disturb" mode: “Resident unavailable”.
- While calling (apartment with no monitor or telephone): “Resident unavailable”.
