~ 4 ~
Input DDC signal
5 Volts [peak-to-peak, TTL]
ESD protection
[1] Human body model — ±19kV [air-gap discharge] & ±12kV [contact discharge]
[2] Core chipset — ±8kV
PCB stack-up
4-layer board [impendence control — differential 100; single 50]
Input
8x HDMI
1x RS-232
1x RJ-45 [HDMI signal]
1x RJ-45 [Channel control]
1x IR socket for IR receiver
Output
8x RJ-45 [HDMI signal]
8x RJ-45 [Channel control]
9x IR socket for IR blaster
1x HDMI
HDMI Input selection
Push-in button / IR remote control / RS-232
Push-in button / IR remote control
HDMI source control
Controllable via IR pass-through from IR receiver at RX to IR blaster at TX
IR remote control
Electro-optical characteristics:  = 25 / Carrier frequency: 38kHz
HDMI connector
Type A [19-pin female]
RJ-45 connector
WE/SS 8P8C with 2 LED indicators [TMDS & DDC channels]
RS-232 connector
DE-9 [9-pin D-sub female]
USB connector
3
Standard type-B [square shape]
3.5mm connector
Earphone jack for IR blaster
[IR Main] IR control on all source devices
[IR PASS-THROUGH1~8] IR control on
individual source device
Earphone jack for IR receiver
[IR RECEIVER] Receives IR commands from
remote control
DIP switch
[MA-5188]
[SW1~SW8] 2-pin for EDID & audio mode
[SW Main] 4-pin for operation & firmware update
Mechanical
MA-5188
MA-5188RX
Enclosure
Metal case
Dimensions
(L x W x H)
Model
440 x 290 x 44mm [1’5” x 11.4” x 1.7”]
85 x 90 x 25mm [3.3” x 3.5” x 1”]
Package
528 x 398 x 130mm [1’9” x 1’4” x 5.1”]
90 x 85 x 25mm [3.5” x 3.3” x 1”]
Carton
585*242*565mm
Weight
Model
3250g [7.2 lbs]
180g [6.3oz]
Package
7.1 kg [15.6 lbs]
Fixedness
1U rack-mount with ears
Wall-mount with screws
Power supply
AC Power 100-240V
Not necessarily required
1
Power consumption
60 Watts [max]
1.5 Watt [max] (provided by MA-5188)
Operation temperature
0~40C [32~104F]
Storage temperature
-20~60C [-4~140F]
Relative humidity
20~90% RH [no condensation]
Package Contents
1x MA-5188
1x IR blaster
2
2x 1U rack mounting-ear
1x IR remote control
2
1x User Manual
8x MA-5188RX
8x IR receiver
16x Wall-mounting screws
1x UL AC power cord
1
The MA-5188RX has been tested extensively and found that it doesn’t require external power supply. If
in rare situation you find it cannot work with the MA-5188, please use any +5V power adapter to plug in
the power jack and see if it can work. If not, please contact your technical support for further service.
2
Additional IR remote control and IR blaster cable can be purchased as optional accessories to control
the HDMI sources located separately.
3
USB or RS-232 control must be connected either one at a time. Connecting both types of cables may
cause command confusion.
