2 Description and Function
2.1 Product
Thisproductisaninfraredmotionsensorforindoorsandisspeciedas
installation material. It reacts to heat radiation (infrared radiation) of moving
objectsthatenterthedetectionareaofthesensor,eg.peopleandanimals,
etc.Thesensormust„see“theareawhichismonitored.Thermalradiation
propagatesinastraightline,butisstoppedbyglassorothersolidobjects.
Entering the detection area of the sensor switches the connected electrical
consumer on and after a (adjustable) time off again automatically. A built-in
photocellpreventsworkingofthemotionsensorduringsunlight.Inaddition,
the ambient brightness can be adjusted by a regulator.
2.2 Product parts
1 2 3 2 4 5
Fi g . 7:Productparts
1 Switch-off delay
2 Mountingclamps
3 Motion sensor
4 TripSensitivity
5 Terminals
2.3 Scope of Delivery
Infra-red motion detector, User manual
2.4 General specications
Voltage 220-240V~50Hz
Standbypower ≤0.5W
Rated load
max.800W(incandescentlamps),
max.400W(energy-savinglamps)
