Goobay VESA User Manual

15
M5x16 B 4
M5 Nut
C 4
Flat screen installation
M6x14 M-A 4
M8x20
M-B 4
Washer D8
M-C 4
TV Spacer
M-D 8
Tab. 10: Scope of Delivery
2.2 Required tools
Tool Figure
Phillipsscrewdriver
Wrench M8
second Person
Tab. 11: Required tools
3 Intended Use
Thisproductismadeformountingatscreenswithspecicscreensizes,
weightsandmountingpoints,whicharesummarizedinchapter“Technicaldata“,
onaverticalwall.Anotherusethandescribedinchapter“Descriptionand
Function“isnotpermitted.Neglegtingandignoringtheseregulationsandsafety
instructionscancauseseriousaccidents,personalinjuryandmaterialdamage.
Alsorefertochapter“WarrantyandLiability“.
3.1 Use restrictions
Onlyuseindryinteriorrooms.
