23
BLOWER PERFORMANCE DATA - HEATING SPEEDS THREE PHASE
X = Heating Temperature Rise Not Recommended.
NOTE: The shaded area indicates ranges in excess of maximum external static pressure allowable when heating. For satisfactory operation,
external static pressure should not exceed 0.5" w.c.
Unit
Static CFM W ATTS RISE CFM W ATTS RISE CFM W ATTS RISE
0.1 1100 342 62 1469 494 47 1655 604 X
0.2 1037 335 66 1409 480 49 1579 587 X
0.3 991 320 69 1327 459 52 1483 567 46
0.4 926 308 74 1257 442 55 1407 547 49
0.5 831 290 X 1163 419 59 1329 522 52
0.6 773 279 X 1094 398 63 1210 498 57
0.7 669 260 X 942 363 73 1036 464 66
0.8---------
GPG1336090M43A* - Rise Range: 45° - 75°
LOW MEDIUM HIGH
