PRODUCT IDENTIFICATION
2
A W U F 3642 1 6 A A
PRODUCT
TYPE:
A: Air Handler
CABINET FINISH:
U: Unpainted
P: Painted
N: Uncased
EXPANSION
DEVICE:
F: Flowrater
T: TXV
(Expansion
Device)
Ceiling Mount & Wall Mount Applications
(Nominal Cooling Capacity/Electric Heat kW)
1803: 1 1/2 Tons Cooling / 3 kW Electric Heat
1805: 1 1/2 Tons Cooling / 5 kW Electric Heat
2405: 2 Tons Cooling / 5 kW Electric Heat
3608: 3 Tons Cooling / 8 kW Electric Heat
3105: 1.5 - 2.5 Tons Cooling / 5kW Electric Heat
3210: 2 - 2.5 Tons Cooling / 10kW Electric Heat
3705: 3 Tons Cooling / 5 kW Electric Heat
3708: 3 Tons Cooling / 8 kW Electric Heat
3710: 3 Tons Cooling / 10 kW Electric Heat
MAJOR
REVISION*
MINOR
REVISION*
ELECTRICAL:
1: 208-230V/1ph/60Hz
APPLICATION
C: Ceiling Mount PSC Motor
D: Downflow PSC Motor
E: Multi-Position Varible Speed Motor
S: Energy-Efficient Motor
R: Multi-Position PSC Motor
T: Coated Coils
W: Wall Mount PSC Motor
REFRIGERANT CHARGE:
No Digit: R-22 Only
6: R-410A or R-22
NOMINAL CAPACITY RANGE:
@ 13 SEER
Dedicated Application
3636: 3 Tons
Multi-Position & Downflow Applications
3137: 3 Tons
3642: 3 - 3 1/2 Tons
1830: 1 1/2 - 3 1/2 Tons
@10 SEER
1729: 1 1/2 - 2 1/2 Tons
for ex
ort s
stems
The model number is used for positive identification of component parts used in manufacturing. Please use this number
when requesting service or parts information.
WARNING
WARNING
HIGH VOLTAGE!
Disconnect ALL power before servicing or installing this unit. Multiple power
sources may be present. Failure to do so may cause property damage, personal
injury or death.
Installation and repair of this unit
should be performed
ONLY by in-
dividuals meeting the require-
ments of an "entry level technician", at a minimum, as
specified by the Air-Conditioning, Heating, and Refrigera-
tion Institute (AHRI). Attempting to install or repair this
unit without such background may result in product
damage, personal injury or death.
Goodman will not be responsible
for any injury or property damage
arising from improper service or service procedures. If
you install or perform service on this unit, you assume
responsibility for any personal injury or property damage
which may result. Many jurisdictions require a license to
install or service heating and air conditioning equipment.
WARNING
WARNING
WARNING
WARNING
All Airhandlers use DIRECT DRIVE MOTORS. Power supply is AC 208-230v, 60 hz, 1 phase.
