PRODUCT SPECIFICATIONS
7
ACNF
ACNF18001
ACNF18051
ACNF18061
ACNF18081
ACNF24001
ACNF24051
ACNF24061
ACNF24081
ANF24101
ACNF30001
ACNF30051
ACNF30061
ACNF30081
ACNF30101
Blower
Diameter 5.75 5.75 5.75 5.75 6.31 6.31 6.31 6.31 6.31 6.75 6.75 6.75 6.75 6.75
Width 6.75 6.75 6.75 6.75 8.25 8.25 8.25 8.25 8.25 8.25 8.25 8.25 8.25 8.25
Coil Drain Connection FPT 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Electrical Data
Min. Circuit Ampacity @ 240V 0.9 27 33.5 40.5 1.68 27.8 34.3 41.3 54.9 1.68 27.8 34.3 41.3 54.9
Min. Circuit Ampacity @ 208V 0.9 2405 30.5 36.8 1.68 25.3 31.36 37.6 49.8 1.68 25.3 31.3 37.6 49
Max. Overcurrent Device 240V 15 30 40 50 15 30 40 50 60 15 30 40 50 8
Max. Overcurrent Device @ 208V 15 30 40 40 15 30 40 40 50 15 30 40 40 60
Minimum VAC 197 197 197 197 197 197 197 197 197 197 197 197 197 50
Maximum VAC 253 253 253 253 253 253 253 253 253 253 253 253 253 253
Blower Motor
FLA 0.72 0.72 0.72 0.72 1.34 1.34 1.34 1.34 1.34 1.34 1.34 1.34 1.34 1.34
HP 1/81/81/81/81/41/41/41/41/41/41/41/41/41/4
Ship Weight (lbs)
59 59 59 59 69 69 69 69 69 79 79 79 79 79
ACNF*****DA (with aluminum coils)
ACNF*****AA/AB (copper coils)
ACNF180016
ACNF180516
ACNF180616
ACNF180816
ACNF240016
ACNF240516
ACNF240616
ACNF240816
ANF241016
ACNF300016
ACNF300516
ACNF300616
ACNF300816
ACNF301016
Blower
Diameter 5.75 5.75 5.75 5.75 6.31 6.31 6.31 6.31 6.31 6.75 6.75 6.75 6.75 6.75
Width 6.756.756.756.758.258.258.258.258.258.258.258.258.258.25
Coil Drain Connection FPT 3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"
Lineset Connection Size
Liquid 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction 3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"3/4"
Electrical Data
Min. Circuit Ampacity @ 240V 0.9 27 33.5 40.6 1.68 27.8 34.3 41.3 54.9 1.68 27.8 34.3 41.3 54.9
Min. Circuit Ampacity @ 208V 0.9 23.5 29.2 35.3 1.68 24.3 36.1 47.8 49.8 1.68 24.3 29.9 36.1 47.8
Max. Overcurrent Device 240V 15 30 35 45 15 30 45 50 60 15 30 35 45 8
Max. Overcurrent Device @ 208V 15 25 30 40 15 25 40 40 50 15 25 30 40 60
Minimum VAC 197 197 197 197 197 197 197 197 197 197 197 197 197 50
Maximum VAC 253 253 253 253 253 253 253 253 253 253 253 253 253 253
Blower Motor
FLA 0.720.720.720.721.341.341.341.341.341.341.341.341.341.34
HP 1/81/81/81/81/41/41/41/41/41/41/41/41/41/4
Ship Weight (lbs)
54 57 57 57 61 64 64 64 64 65 68 68 68 68
