  59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1350
MBh 39.3 40.7 44.6 - 38.3 39.7 43.5 - 37.4 38.8 42.5 - 36.5 37.8 41.5 - 34.7 36.0 39.4 - 32.1 33.3 36.5 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.47 - 0.83 0.70 0.48 - 0.84 0.70 0.49 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
kW 2.43 2.49 2.57 - 2.63 2.69 2.78 - 2.81 2.87 2.97 - 2.96 3.03 3.14 - 3.09 3.17 3.28 - 3.21 3.28 3.40 -
Amps 9.9 10.1 10.4 - 10.7 10.9 11.3 - 11.6 11.9 12.3 - 12.4 12.7 13.1 - 13.2 13.5 14.0 - 14.0 14.3 14.8 -
HI PR 214 231 244 - 241 259 273 - 274 294 311 - 312 335 354 - 351 377 398 - 387 417 440 -
LO PR 107 114 124 - 113 120 132 - 118 125 137 - 124 132 144 - 130 138 150 - 134 143 156 -
1217
MBh 38.7 40.1 43.9 - 37.8 39.2 42.9 - 36.9 38.2 41.9 - 36.0 37.3 40.9 - 34.2 35.4 38.8 - 31.7 32.8 35.9 -
S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -
∆T 21 18 13 - 21 18 14 - 21 18 14 - 21 18 14 - 21 18 14 - 19 17 13 -
kW 2.42 2.47 2.56 - 2.62 2.68 2.77 - 2.79 2.85 2.95 - 2.94 3.01 3.12 - 3.07 3.15 3.26 - 3.19 3.26 3.38 -
Amps 9.8 10.0 10.4 - 10.6 10.9 11.2 - 11.5 11.8 12.2 - 12.3 12.6 13.0 - 13.1 13.4 13.9 - 13.9 14.2 14.7 -
HI PR 213 229 242 - 239 257 271 - 272 292 309 - 309 333 352 - 348 375 396 - 385 414 437 -
LO PR 106 113 124 - 112 120 131 - 117 124 136 - 123 131 143 - 129 137 149 - 133 142 155 -
1050
MBh 35.7 37.0 40.5 - 34.9 36.1 39.6 - 34.0 35.3 38.6
- 33.2 34.4 37.7 - 31.5 32.7 35.8 - 29.2 30.3 33.2 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.78 0.65 0.45 -
∆T 21 18 14 - 21 19 14 - 21 19 14 - 22 19 14 - 21 18 14 - 20 17 13 -
kW 2.36 2.41 2.49 - 2.55 2.61 2.69 - 2.72 2.78 2.88 - 2.87 2.93 3.03 - 2.99 3.06 3.17 - 3.10 3.18 3.29 -
Amps 9.5
9.8 10.1 - 10.3 10.6 10.9 - 11.2 11.5 11.8 - 12.0 12.3 12.7 - 12.7 13.0 13.5 - 13.5 13.8 14.3 -
HI PR 207 222 235 - 232 249 263 - 264 284 299 - 300 323 341 - 338 363 384 - 373 401 424 -
LO PR 103 110 120 - 109 116 127 - 113 121 132 - 119 127 138 - 125 133 145 - 129 137 150 -
75
1350
MBh 39.92 41.10 44.49 47.75 38.99 40.14 43.45 46.64 38.06 39.19 42.42 45.52 37.13 38.23 41.38 44.41 35.28 36.32 39.31 42.19 32.68 33.64 36.42 39.08
S/T 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.38 0.89 0.79 0.60 0.39 0.91 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42
∆T 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 23 21 17 12 21 20 16 11
kW 2.45 2.51 2.59 2.68 2.65 2.72 2.81 2.90 2.83 2.90 3.00 3.10 2.99 3.06 3.16 3.27 3.12 3.19 3.31 3.42 3.24 3.31 3.43 3.55
Amps 10.0 10.2 10.5 10.9 10.8 11.0 11.4 11.8 11.7 12.0 12.4 12.8 12.5 12.8 13.2 13.7 13.3 13.6 14.1 14.6 14.1 14.4 14.9 15.5
HI PR 217 233 246 257 243 262 276 288 276 297 314 328 315 339 358 373 354 381 402 420 391 421 445 464
LO PR 108 115 126 134 114 122 133 142 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
1217
MBh 39.3 40.5 43.8 47.0 38.4 39.6 42.8 45.9 37.5 38.6 41.8 44.9 36.6 37.7 40.8 43.8 34.8 35.8 38.7 41.6 32.2 33.1 35.9 38.5
S/T 0.80 0.71 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40
∆T 24 22 18 12 24 22 18 13
24 22 18 13 24 22 18 13 24 22 18 12 22 21 17 12
kW 2.44 2.49 2.58 2.67 2.64 2.70 2.79 2.89 2.81 2.88 2.98 3.08 2.97 3.04 3.14 3.25 3.10 3.17 3.28 3.40 3.22 3.29 3.41 3.53
Amps 9.9
10.1 10.5 10.9 10.7 11.0 11.3 11.7 11.6 11.9 12.3 12.8 12.4 12.7 13.1 13.6 13.2 13.5 14.0 14.5 14.0 14.4 14.8 15.4
HI PR 215 231 244 255 241 260 274 286 274 295 312 325 313 336 355 370 352 378 400 417 389 418 442 461
LO PR 108 114 125 133 114 121 132 141 118 126 137 146 124 132 144 153 130 138 151 161 134 143 156 166
1050
MBh 36.3 37.4 40.5 43.4 35.5 36.5 39.5 42.4 34.6 35.6 38.6 41.4 33.8 34.8 37.6 40.4 32.1 33.0 35.8 38.4 29.7 30.6 33.1 35.5
S/T 0.77 0.69 0.52 0.34 0.80 0.71 0.54 0.35 0.82 0.73 0.55 0.36 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.88 0.79 0.60 0.38
∆T 24 23 18 13 25 23 19 13 25 23 19 13 25 23 19 13 25 23 19 13 23 21 17 12
kW 2.38 2.43 2.51 2.60 2.57 2.63 2.72 2.81 2.74 2.80 2.90 3.00 2.89 2.96 3.06 3.17 3.02 3.09 3.20 3.31 3.13 3.20 3.32 3.43
Amps 9.6 9.9 10.2 10.6 10.4 10.7 11.0 11.4 11.3 11.6 12.0 12.4 12.1 12.4 12.8 13.3 12.9 13.2 13.6 14.1 13.6 14.0 14.4 15.0
HI PR 209 224 237 247 234 252 266 277 266 286 303 316 303 326 345 359 341 367 388 404 377 406 428 447
LO PR 104 111 121 129 110 117 128 136 115 122 133 142 120 128 140 149 126 134 146 156 130 139 151 161
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
Expanded Cooling Data — DSXC160601B* / CA*F4961*6A*+TXV / MBVC2000**-1** Low Stage
