CONDENSING UNIT SPECIFICATIONS
6
GSC130[18-36]1*
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device:
MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
(3)
Installer will need to supply 3/4" to 7/8" adapters for suction line connectors
(4)
Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit
breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
GSC130[18-24]1*
GSC130[30-36]1*
GSC130181BB GSC130181DA GSC130181FA GSC130241DB GSC130241EA GSC130241FA
Nominal Cooling Capacity, BTUH 18,000 18,000 18,000 24,000 24,000 24,000
Compressor
R.L. Amps 6.2 6.4 6.4 7.8 8.0 10.8
L.R. Amps 35 36 36 40 41 56
Condenser Fan Motor
Horsepower 1/61/81/81/61/81/8
F.L. Amps 1.50.70.71.10.70.7
Refrigerant Line Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Refrigerant Connection Size
Liquid Valve Size O.D. 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Valve Size O.D. 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Refrigerant Charge 81 75 75 83 77 77
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
8.9 8.7 8.7 10.9 10.7 14.2
Maximum Overcurrent Device
(2)
15 15 15 15 15 25
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 145 142 130 195 142 130
GSC130301DB GSC130301E* GSC130361FB GSC130361GA
Nominal Cooling Capacity, BTUH 30,000 30,000 36,000 36,000
Compressor
R.L. Amps 9.7 13.5 12.2 13.4
L.R. Amps 49 68 73 74
Condenser Fan Motor
Horsepower 1/6 1/8 1/6 1/6
F.L. Amps 1.1 0.7 1.1 1.1
Refrigerant Line Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 3/4" 3/4" 7/8" 7/8"
Refrigerant Connection Size
Liquid Valve Size O.D. 3/8" 3/8" 3/8" 3/8"
Suction Valve Size O.D.
3/4"
(3 )
3/4"
(3)
3/4"
(3)
3/4"
(3)
Refrigerant Charge 87 66 83 77
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
13.2 17.6 16.4 17.9
Maximum Overcurrent Device
(2)
20 30 25 30
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 172 136 205 177
