CONDENSING UNIT SPECIFICATIONS
7
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device:
MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
(3)
Installer will need to supply 3/4" to 7/8" adapters for suction line connectors
(4)
Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit
breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
GSC130[42-60]1*
GSC130421BB GSC130481BB GSC130601CB
Nominal Cooling Capacity, BTUH 42,000 48,000 57,000
Compressor
R.L. Amps 19.2 17.9 19.9
L.R. Amps 104 104 137
Condenser Fan Motor
Horsepower 1/4 1/4 1/4
F.L. Amps 1.5 1.5 1.5
Refrigerant Line Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 1-1/8" 1-1/8" 1-1/8"
Refrigerant Connection Size
Liquid Valve Size O.D. 3/8" 3/8" 3/8"
Suction Valve Size O.D.
7/8"
4
7/8"
4
7/8"
4
Refrigerant Charge 95 102 131
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
25.5 23.9 26.4
Maximum Overcurrent Device
(2 )
40 40 45
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 199 210 242
GSC130[42-60]1*
