CONDENSING UNIT SPECIFICATIONS
8
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device:
MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
(3)
Installer will need to supply 3/4" to 7/8" adapters for suction line connectors
(4)
Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit
breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
GSC130363B* GSC130483B* GSC130603B* GSC130484B* GSC130604B*
Nominal Cooling Capacity, BTUH 36,000 48,000 57,000 45,500 55,500
Compressor
R.L. Amps 9.0 12.4 14.7 5.8 7.1
L.R. Amps 65.5 88.0 91.0 44.0 50.0
Condenser Fan Motor
Horsepower 1/6 1/4 1/4 1/4 1/4
F.L. Amps 1.1 1.5 1.5 0.8 0.8
Refrigerant Line Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 7/8" 1-1/8" 1-1/8" 1-1/8" 1-1/8"
Refrigerant Connection Size
Liquid Valve Size O.D. 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Valve Size O.D.
3/4"
3
7/8"
4
7/8"
4
7/8"
4
7/8"
4
Refrigerant Charge 83 89 131 102 131
Power Supply 208/230-60-3 208/230-60-3 208/230-60-3 460-60-3 460-60-3
Minimum Circuit Ampacity
(1)
12.4 17 19.9 8 9.7
Maximum Overcurrent Device
(2)
20 20 30 15 15
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 214 207 242 207 242
