Goodman SSZ14 User Manual

12 www.goodmanmfg.com SS-SSZ14
ExpandEd data
Cooling Data —SSZ140381a* / aSpt42C14a*
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1050
MBh 30.4 31.5 34.5 - 29.7 30.7 33.7 - 29.0 30.0 32.9 - 28.2 29.3 32.1 - 26.8 27.8 30.5 - 24.9 25.8 28.2 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.81 0.68 0.47 -
∆T 19 16 12 - 19 16 12 - 19 16 12 - 19 17 13 - 19 16 12 - 18 15 12 -
kW 2.68 2.68 2.68 - 2.68 2.68 2.68 - 2.69 2.69 2.69 - 2.69 2.69 2.69 - 2.69 2.69 2.69 - 2.69 2.69 2.69 -
Amps 10.9 10.9 10.9 - 10.9 10.9 10.9 - 10.9 11.0 11.0 - 11.0 11.0 11.0 - 11.0 11.0 11.1 - 11.1 11.1 11.1 -
Hi PR 211 228 240 - 237 255 270 - 270 290 307 - 307 331 349 - 346 372 393 - 382 411 434 -
Lo PR 104 110 120 - 110 117 127 - 114 121 132 - 120 127 139 - 125 133 146 - 130 138 151 -
1175
MBh 32.0 33.1 36.3 - 31.2 32.4 35.5 - 30.5 31.6 34.6 - 29.7 30.8 33.8 - 28.2 29.3 32.1 - 26.2 27.1 29.7 -
S/T 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -
∆T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
kW 2.68 2.68 2.68 - 2.68 2.68 2.69 - 2.69 2.69 2.69 - 2.69 2.69 2.69 - 2.69 2.69 2.69 - 2.69 2.69 2.69 -
Amps 10.9 10.9 10.9 - 10.9 10.9 10.9 - 10.9 11.0 11.0 - 11.0 11.0 11.0 - 11.0 11.0 11.1 - 11.1 11.1 11.1 -
Hi PR 216 232 245 - 242 261 275 - 275 296 313 - 314 338 356 - 353 380 401 - 390 420 443 -
Lo PR 106 113 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 149 - 132 141 154 -
1350
MBh 32.9 34.1 37.4 - 32.2 33.3 36.5 - 31.4 32.5 35.7
- 30.6 31.7 34.8 - 29.1 30.2 33.0 - 27.0 27.9 30.6 -
S/T 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.82 0.69 0.47 - 0.85 0.71 0.49 - 0.88 0.73 0.51 - 0.89 0.74 0.51 -
∆T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
kW 2.68 2.68 2.68 - 2.68 2.68 2.69 - 2.69 2.69 2.69 - 2.69 2.69 2.69 - 2.69 2.69 2.69 - 2.69 2.69 2.69 -
Amps 10.9 10.9
10.9 - 10.9 10.9 10.9 - 11.0 11.0 11.0 - 11.0 11.0 11.0 - 11.0 11.1 11.1 - 11.1 11.1 11.1 -
Hi PR 218 235 248 - 245 263 278 - 278 299 316 - 317 341 360 - 356 384 405 - 394 424 447 -
Lo PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 137 150 - 134 142 155 -
75
1050
MBh 30.9 31.8 34.4 36.9 30.2 31.1 33.6 36.1 29.4 30.3 32.8 35.2 28.7 29.6 32.0 34.4 27.3 28.1 30.4 32.6 25.3 26.0 28.2 30.2
S/T 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.82 0.62 0.40 0.92 0.82 0.62 0.40
∆T 22 20 16 11 22 20 17 11 22 20 17 11 22 20 17 12 22 20 16 11 20 19 15 11
kW 2.68 2.68 2.68 2.68 2.68 2.68 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69
Amps 10.9 10.9 10.9 10.9 10.9 10.9 10.9 10.9 10.9 11.0 11.0 11.0 11.0 11.0 11.0 11.0 11.0 11.0 11.1 11.1 11.1 11.1 11.1 11.1
Hi PR 214 230 243 253 240 258 272 284 273 293 310 323 311 334 353 368 349 376 397 414 386 415 439 457
Lo PR 105 111 122 130 111 118 129 137 115 122 134 142 121 129 140 150 127 135 147 157 131 139 152 162
1175
MBh 32.5 33.5 36.2 38.9 31.8 32.7 35.4 38.0 31.0 31.9 34.5 37.1 30.2 31.1 33.7 36.2 28.7 29.6 32.0 34.4 26.6 27.4 29.7 31.8
S/T 0.84 0.75 0.57 0.36 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.42 0.96 0.86 0.65 0.42
∆T 21 20 16 11 22 20 16 11
22 20 16 11 22 20 16 11 21 20 16 11 20 18 15 10
kW 2.68 2.68 2.68 2.68 2.68 2.68 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69
Amps 10.9 10.9
10.9 10.9 10.9 10.9 10.9 11.0 11.0 11.0 11.0 11.0 11.0 11.0 11.0 11.1 11.0 11.1 11.1 11.1 11.1 11.1 11.1 11.1
Hi PR 218 235 248 258 245 263 278 290 278 299 316 330 317 341 360 376 356 384 405 422 394 424 448 467
Lo PR 107 114 124 132 113 120 131 140 117 125 136 145 123 131 143 153 129 138 150 160 134 142 155 165
1350
MBh 33.5 34.5 37.3 40.0 32.7 33.7 36.4 39.1 31.9 32.9 35.6 38.2 31.1 32.1 34.7 37.3 29.6 30.5 33.0 35.4 27.4 28.2 30.5 32.8
S/T 0.88 0.79 0.59 0.38 0.91 0.81 0.62 0.40 0.93 0.83 0.63 0.41 0.96 0.86 0.65 0.42 1.00 0.89 0.68 0.44 1.00 0.90 0.68 0.44
∆T 20 18 15 10 20 19 15 11 20 19 15 11 20 19 15 11 20 19 15 10 19 17 14 10
kW 2.68 2.68 2.68 2.68 2.68 2.68 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69 2.69
Amps 10.9 10.9 10.9 10.9 10.9 10.9 10.9 11.0 11.0 11.0 11.0 11.0 11.0 11.0 11.0 11.1 11.0 11.1 11.1 11.1 11.1 11.1 11.1 11.2
Hi PR 220 237 250 261 247 266 281 293 281 302 319 333 320 344 364 379 360 387 409 427 398 428 452 471
Lo PR 108 115 125 134 114 121 133 141 119 126 138 147 125 133 145 154 131 139 152 161 135 144 157 167
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)

Goodman SSZ14 Specifications

General

Brand	Goodman
Model	SSZ14
Category	Heat Pump
Language	English
