ExpandEd data
Cooling Data — SSZ140241a* / Ca*f3636*6a*+tXV / mBr800**-1
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
956
MBh 23.5 24.4 26.7 - 23.0 23.8 26.1 - 22.4 23.2 25.5 - 21.9 22.7 24.8 - 20.8 21.5 23.6 - 19.3 20.0 21.9 -
S/T 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.87 0.72 0.50 -
∆T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 11 -
kW 1.65 1.68 1.73 - 1.77 1.80 1.86 - 1.87 1.91 1.97 - 1.97 2.01 2.07 - 2.04 2.09 2.15 - 2.11 2.16 2.22 -
Amps 10.1 10.2 10.4 - 10.5 10.7 10.9 - 11.0 11.2 11.4 - 11.5 11.7 11.9 - 12.0 12.2 12.4 - 12.4 12.6 12.9 -
Hi PR 222 239 252 - 249 268 283 - 283 305 322 - 323 347 367 - 363 391 412 - 401 432 456 -
Lo PR 110 117 128 - 116 124 135 - 121 129 140 - 127 135 147 - 133 142 155 - 138 146 160 -
850
MBh 22.8 23.7 25.9 - 22.3 23.1 25.3 - 21.8 22.6 24.7 - 21.2 22.0 24.1 - 20.2 20.9 22.9 - 18.7 19.4 21.2 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.83 0.69 0.48 -
∆T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 15 12 - 17 14 11 -
kW 1.64 1.67 1.72 - 1.75 1.79 1.84 - 1.86 1.90 1.95 - 1.95 1.99 2.05 - 2.03 2.07 2.14 - 2.09 2.14 2.21 -
Amps 10.0 10.1 10.3 - 10.5 10.6 10.8 - 11.0 11.1 11.4 - 11.4 11.6 11.9 - 11.9 12.1 12.3 - 12.3 12.5 12.8 -
Hi PR 220 236 250 - 247 265 280 - 280 302 319 - 319 344 363 - 359 387 408 - 397 427 451 -
Lo PR 109 116 127 - 115 122 134 - 120 127 139 - 126 134 146 - 132 140 153 - 136 145 158 -
744
MBh 21.1 21.8 23.9 - 20.6 21.3 23.4 - 20.1 20.8 22.8
- 19.6 20.3 22.3 - 18.6 19.3 21.1 - 17.3 17.9 19.6 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -
∆T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
kW 1.60 1.63 1.68 - 1.72 1.75 1.80 - 1.82 1.85 1.91 - 1.90 1.94 2.00 - 1.98 2.02 2.08 - 2.04 2.09 2.15 -
Amps 9.8 10.0
10.2 - 10.3 10.4 10.6 - 10.8 11.0 11.2 - 11.2 11.4 11.7 - 11.7 11.9 12.1 - 12.1 12.3 12.6 -
Hi PR 213 229 242 - 239 257 272 - 272 293 309 - 310 333 352 - 349 375 396 - 385 414 438 -
Lo PR 106 112 123 - 112 119 130 - 116 123 135 - 122 130 142 - 128 136 148 - 132 141 153 -
75
956
MBh 23.9 24.6 26.7 28.6 23.4 24.1 26.0 27.9 22.8 23.5 25.4 27.3 22.2 22.9 24.8 26.6 21.1 21.8 23.6 25.3 19.6 20.2 21.8 23.4
S/T 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.98 0.87 0.66 0.42 0.98 0.88 0.67 0.43
∆T 20 18 15 10 20 18 15 10 20 18 15 10 20 19 15 10 20 18 15 10 19 17 14 10
kW 1.66 1.70 1.75 1.80 1.78 1.82 1.87 1.93 1.89 1.93 1.99 2.05 1.98 2.02 2.09 2.15 2.06 2.10 2.17 2.24 2.13 2.17 2.24 2.32
Amps 10.1 10.2 10.4 10.7 10.6 10.7 10.9 11.2 11.1 11.3 11.5 11.8 11.6 11.8 12.0 12.3 12.0 12.2 12.5 12.8 12.5 12.7 13.0 13.3
Hi PR 224 241 255 266 252 271 286 298 286 308 325 339 326 351 370 386 367 395 417 435 405 436 460 480
Lo PR 111 118 129 138 117 125 136 145 122 130 142 151 128 136 149 159 134 143 156 166 139 148 161 172
850
MBh 23.2 23.9 25.9 27.8 22.7 23.4 25.3 27.1 22.1 22.8 24.7 26.5 21.6 22.2 24.1 25.8 20.5 21.1 22.9 24.5 19.0 19.6 21.2 22.7
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.41 0.94 0.84 0.63 0.41
∆T 21 19 15 11 21 19 16 11
21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10
kW 1.65 1.68 1.73 1.78 1.77 1.80 1.86 1.92 1.87 1.91 1.97 2.03 1.97 2.01 2.07 2.13 2.04 2.09 2.15 2.22 2.11 2.16 2.22 2.30
Amps 10.1 10.2
10.4 10.6 10.5 10.7 10.9 11.1 11.0 11.2 11.4 11.7 11.5 11.7 11.9 12.2 12.0 12.2 12.4 12.7 12.4 12.6 12.9 13.2
Hi PR 222 239 252 263 249 268 283 295 283 305 322 336 323 347 367 382 363 391 412 430 401 432 456 475
Lo PR 110 117 128 136 116 124 135 144 121 129 140 150 127 135 147 157 133 142 155 165 138 146 160 170
744
MBh 21.4 22.1 23.9 25.6 20.9 21.6 23.3 25.0 20.4 21.0 22.8 24.4 19.9 20.5 22.2 23.8 18.9 19.5 21.1 22.7 17.5 18.1 19.6 21.0
S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39
∆T 21 19 16 11 21 19 16 11 21 19 16 11 21 20 16 11 21 19 16 11 20 18 15 10
kW 1.61 1.64 1.69 1.74 1.73 1.76 1.82 1.87 1.83 1.87 1.92 1.98 1.92 1.96 2.02 2.08 2.00 2.04 2.10 2.17 2.06 2.10 2.17 2.24
Amps 9.9 10.0 10.2 10.4 10.3 10.5 10.7 10.9 10.9 11.0 11.2 11.5 11.3 11.5 11.7 12.0 11.8 11.9 12.2 12.5 12.2 12.4 12.7 13.0
Hi PR 215 232 245 255 242 260 275 286 275 296 312 326 313 337 356 371 352 379 400 417 389 419 442 461
Lo PR 107 114 124 132 113 120 131 140 117 125 136 145 123 131 143 152 129 137 150 160 133 142 155 165
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
To Next Page
