2.4 Indicator
CDG Indicator
Indicates when a CD+G track
is being played.
Play/Pause Indicator
Indicates when in play or pause mode.
Prog Indicator
Indicates when the program function
is active.
Repeat Indicator
Indicates when the repeat mode is active.
2.5 Rear View
2.6 Top View
LED Light
DISC Compartment
Indicates when a CD+G track
is being played.
RCA Stereo Right Audio Outputs
Connect to an RCA stereo input or a
TV or amplifier.
DC MAINS input
Indicates when the repeat mode is active.
Composite Video Output
Connect to a TV video input.
RCA Stereo Left Audio Outputs
Connect to an RCA stereo input on a
TV or amplifier
