Goodmans XB25CDG - Location of Controls; Front Panel Controls; Back Panel Connections

4
LOCATION OF CONTROLS
FRONT PANEL
1. Power Button
2. DBBS Indicator
3. Disc Skip Button
4. Mute Indicator
5. 3 CD Changer
6. Standby/on Indicator
7. LCD Display
8. Disc1,2,3 Selector
9. CD Door Open/Close Button
10. Mute Button
11. DBBS Button
12. Hi-Speed Dubbing Button
13. Auto Vocal ON/OFF Switch
14. Volume Control
15. CD Play/Pause Button
16. CD Stop Button
17. Repeat Button
18. Cassette Deck B
19. Mix Music Vocal Control
20. Echo Control
21. MIC 2 Volume Control
22. MIC 1 Volume Control
23. MIC 2 Input Socket
24. MIC 1 Input Socket
25. Cassette Deck A
26. Program Button
27. CD Skip Down Button
28. CD Skip Up Button
29. Headphone Socket
30. Function Selector(AUX-TAPE-CD)
BACK PANEL
1. AC Power Cord
2. Mains Power Switch
3. AUX-OUT Socket
4. AUX-IN Socket
5. Scart Socket
6. BS Plug Storage Slot
7. MIC Hooks
8. Carrying Handles
1
2
3
4
5
67 8
9
10
12
11
13
14
15
16
17
18
192021222324
30
29
28
27
26
25
12
43
887 65
7
