WX-950
Installation Manual
A-5
Rev. C
SIGNAL CHARACTERISTICS
Power Input 11-32 VDC. The WX-950 is protected via an internal fuse (see para 4.6). For
external circuit breaker protection, a 5 A circuit breaker is recommended
for 14 V aircraft systems and a 3 A circuit breaker for 28 V systems.
CONNECTION J1-8, & J1-21 (A/C POWER 14-28 VOLTS)
J1-7 & J1-20 (A/C GROUND)
CABLE Use twisted shielded pair cable, minimum 20 AWG.
VOLTAGE 11 - 32 VDC
CURRENT 2.0 A ± 0.5 A @ 12 VDC
0.8 A ± 0.25 A @ 28 VDC
Configuration Jumper The configuration jumper connection is available to support factory testing
and analysis and
SHOULD BE LEFT UNCONNECTED.
CONNECTION J1-9 (CONFIG_JUMPER)
