WX-950
Installation Manual
1-1
Rev. C
CHAPTER 1
GENERAL INFORMATION
1.1 INTRODUCTION
This section contains a functional description of the Stormscope® model WX-950 Series II weather
mapping system, outlines the main features of the system, and provides a functional block diagram. The
basic WX-950 System (see table 1-1) consists of the following equipment:
Display/Processor P/N 805-10950-001 (Black Bezel) or P/N 805-10950-002 (Gray Bezel)
NY-163 Antenna P/N 805-10930-001 (White) or P/N 805-10930-002 (Black)
Installation Kit P/N 817-10950-001
Antenna Cable (ordered separately). Antenna cables, with the antenna connector pre-wired to
one end, are available in 6, 12, 25, 50 and 75 ft. lengths (see table 1-2). To meet different space
requirements the antenna connector can be ordered with either a straight or right-angle
backshell. Most installations will require the right-angle backshell.
Components supplied with the installation kit are identified in tables 1-3 and 1-4.
Table 1-1. WX-950 System Part Numbers
BEZEL ANTENNA
SYSTEM P/N BLACK GRAY WHITE BLACK
830-10950-001 X X
830-10950-002 X X
830-10950-003 X X
830-10950-004 X X
Table 1-2. Antenna Cable Part Numbers
PART NUMBER
LENGTH
(ft.)
RIGHT-ANGLE
BACKSHELL
STRAIGHT
BACKSHELL
6 803-10950-004 803-10952-004
12 803-10950-005 803-10952-005
25 803-10950-001 803-10952-001
50 803-10950-002 803-10952-002
75 803-10950-003 803-10952-003
Table 1-3. WX-950 Installation Kit P/N 817-10950-001
QUANTITY PART NUMBER DESCRIPTION
1 78-8060-5979-2 Antenna Doubler Plate
1 78-8060-5977-6 Antenna Gasket
1 817-10951-001 Hardware Package (see table 1-4)
Table 1-4. Hardware Package P/N 817-10951-001
QUANTITY PART NUMBER DESCRIPTION
1 814-10956-001 Rear Cable Connector Assembly
1 814-10959-001 Connector Shell Assembly
1 78-8060-5733-3 Circuit Breaker Label
1 606-10010-001 Cable Clamp, 7/16”
1 606-10009-001 Cable Clamp, 3/8”
2 606-10012-001 Cable Tie, 5-5/8”
2 101-10091-001 Brass Locking Terminal
4 100-10075-001 Screw, 6-32 x 1/2 PP SS Black Oxide UNC-2A
3 101-10098-001 Stop Nut, Elastic 10-32 S.S.
2 26-1004-1394-2 Washer, .2 ID x .325 OD S.S.
3 26-1004-9316-7 Stop Nut, Elastic 4-40
2 26-1004-9152-6 Screw, 10-32 x 1 1/2 PPH S.S.
2 26-1010-0057-3 Screw, 10-32 x 3/8 TRUS PH S.S.
