Goodwe GM3000 Quick Installation Guide

7
Quick Installation Guide V1.0-2022-01-25
Model GM1000D GM1000 GM3000
Application Single-phase Single-phase Three-phase
Voltage
Nominal Voltage 110V/230V 3 x 230V/380V
Voltage Range 100V~240V
Frequency 50Hz/60Hz
Current Input
Nominal Current CT in: 120A/40mA
Current Range 0.48A~120A
Self-Consumption <3W
Data Detection
Current/Voltage/Active Power/Reactive Power/Power
Factor/Frequency
Energy Calculation Active/Reactive Power Energy
Precision
Voltage/Current Class I
Active Power Class I
Reactive Power Class II
Communication
RS485(Bund Rate 9600/Modbus Protocol/
Communication cable max.length 100m)
Interface
3 LED (Power, Energy Consumption, Communication),
USB port, Reset button
Mechanical
Size (L x W x H mm) 36 x 85 x 66.5
Weight 360g 250g 450g
Protection Class IP20 (For indoor use)
Installation
Method
Mounting rack
Operating Temperature -25 ~ +60° C
Operating Humidity <95%, No condensation
Altitude <2000m
Technical Parameters
05

Goodwe GM3000 Specifications

General

Brand	Goodwe
Model	GM3000
Category	Measuring Instruments
Language	English
