Goodwe GMK120 - Installation

12
Packing List
04 Installation
x 1
[1]
x 1
[4]
x 1
[2]
x 1
[2]
x 1
[2]
x 1
[3]
x 14
x 1
x 1
[3]
x 1
x 4
[4]
x 4
[4]
For specic CT wirings, refer to the documents provided by the respective manufacturer.
Example CT2
GM330
L1/L2/L3
Direction of
the current
House
Grid
[1]. GMK120:CT x 3; GMK140: CT x 6; GM330 is not equipped with CT.
[2]. Only for GM330.
[3]. Only for GMK120, GMK140.
[4]. Optional.
