Model GMK120 GMK140 GM330
Technical parameters
Input
Grid
Single-phase(L/N ≤ 265Vac)
Split-phase(L/N≤ 265Vac)
Three-phase(3-wire,L/L≤
265Vac)
Three-phase(4-wire,L/N≤
265Vac)
Three-phase(3-
wire,L/L ≤ 576Vac)
Three-phase(4-
wire,L/N ≤ 520Vac)
Frequency 50/60Hz
Voltage
Rated voltage 208V, 120V / 240V 277V/480V
Voltage range 0.88Un-1.1Un
Current
Rated current 200A 5A(MAX)
Current range 0-200A 0-5A
Communication RS485 interface, Modbus-RTU
Communication Distance RS485:1000m(Use shielded twisted-pair cables)
Display and button
4 LED (Power supply and network communication
indicator,Wireless indicator(reserved),Energy
consumption indicator1,Energy consumption
indicator2), Reset button
Measurement precision
Voltage/Current: 0.5 level
Active energy: 0.5 level
Reactive energy: 1 level
Power supply Power consumption ≤5W
Structural
parameters
Dimension (L x W x H) 85 x 72 x 72mm/33.5×28.3×28.3in
Weight 240g/0.53lb
Installtion Rail installation
Environment
paraments
Protection class IP20
Working temperature -30℃-+70℃/-22℉-+158℉
Storage temperature -30℃-+70℃/-22℉-+158℉
Relative humidity 0%-95%, non-condensing
Altitude ≤ 3000m/9842ft
07 Technical Parameters
NOTICE
The smart meter is mainly used for power control at the grid-connection point. The
measured energy yield and electricity consumption are for reference only and cannot be
used as a basis for calculating electricity fees. Electricity fee measurement is subject to the
meter provided by the grid company.
