Check that the cabinet and the cut-out meet the
dimension and ventilation requirement
Threat the sawn ends of wooden or synthetic worktops
with sealing varnish if necessary, to prevent moisture
causing the worktop to swell.
Lay the hob upside down on the worktop.
Fit the connecting cable to the appliance in compliance
with requirements
Remove the protective layer from the sealing tape and
apply the tape in the groove of the aluminium profi le or
on the edge of the glass plate. Do not stick tape round the
corners, but cut 4 separate pieces to seal the corners well.
Turn the hob over and lay it in the recess.
Connect the appliance to the mains. A short bleep will
be heard and all the displays will light up briefl y. The
appliance is ready for use.
Check that it works properly. If the appliance has been
wrongly connected either a bleep will sound or nothing
will appear in the displays, depending on the error.
Building in
