Common installation practice
Installing T-nuts
When installing T-nuts into the wood, use a smooth faced hammer to set the face
of the T-nut flush into the wood.
Insert the barrel of the T-nut into the
predrilled hole. Using a smooth faced
hammer, drive the T-nut until the face
of the T-nut is flush to the wood.
This picture shows the T-nut insert and
installed flush to the wood.
This picture shows an end view of the T-nut
insert and installed flush to the wood.
WARNING: DO NOT EMBED THE TOP OF THE
T-NUT INTO THE FACE OF THE WOOD
Cross Section end views, you are looking at an X-
ray view of the post and T-nut. The barrel of the
T-nut is in the corner post the line is the face of
the wood.
